AmeriGlide Hercules II Commercial Lift
Call 1 (877) 852-3216 for the lowest price!
AmeriGlide's Hercules II Commercial Platform Lift is the premier vertical platform lift solution for nearly any commercial application including restaurant and mall fronts, public building entrances, places of worship, and event locations such as stadiums and arenas.
Standard features include a 600 pound capacity, solid handrail, solid platform, safety pan switch, and top and bottom limits. The lift is both ASME A18.1, Section 2 and CSA B44.1 - ASME 17.5 compliant when correctly configured.
Commercial Lift Note: Final approval of commercial platform lifts is dependent on your local elevator branch. Please consult with them for exact code requirements in your area.
Standard features include a 600 pound capacity, solid handrail, solid platform, safety pan switch, and top and bottom limits. The lift is both ASME A18.1, Section 2 and CSA B44.1 - ASME 17.5 compliant when correctly configured.
Commercial Lift Note: Final approval of commercial platform lifts is dependent on your local elevator branch. Please consult with them for exact code requirements in your area.
Additional Images
Click on an image to enlarge.
- Lifting Capacity: 600 lb
- Standard Lift Height: 53"
- Maximum Lift Height Upgrade: 171"
- Lift Speed (FPM): 10
- Maximum Stops: 3
- Portable: No
- Arrives Assembled: No
- Drive System: 53" - 125" Acme Screw Drive, 149" - 171" Ball Screw Drive
- Optional Drive Systems: None Available
- Battery Powered Option: Yes
- Constant Pressure Platform Control: Yes
- Emergency Stop Platform Control: Included
- Alarm Button: Optional Audible Alarm
- Keyed Platform Control: Optional
- Call-Send Controls: Optional Non-Keyed & Keyed Call-Send
- Platform Type: Solid with Non-Skid Coating
- Platform Size: 36" x 54" Platform (34" Usable Width)
- Optional Platform Sizes: 36" x 60" (34" Usable Width), 42" x 54" (40" Usable Width)
- Platform Configuration: Straight-Thru Access
- Optional Platform Configurations: Same Side Entry-Exit, Adjacent Access
- Upper Landing Gate: Optional
- Upper Access Ramp: None Available
- Lower Access Ramp: Fixed, Optional Automatic
- Grab Rail: Included
- Guard Panel: 42"
Product Video
- Lifting Height
- Crating & Assembly
- Tower Orientation
- Power Source
- Electronics
- Platform Type
- Platform Access
- Platform Gate
- Platform Controls
- Platform Control Options
- Platform Options
- Ramp Type & Pit Switch
- Landing Controls
- Landing Gate
- Fire Rated Doors
- Interlocks
- Accessories
- Additional Delivery Services
- 53" Max Lift Height, Acme Screw Drive
$0.00
- 77" Max Lift Height, Acme Screw Drive
$730.00
- 101" Max Lift Height, Acme Screw Drive
$1,840.00
- 125" Max Lift Height, Acme Screw Drive
$3,450.00
- 149" Max Lift Height, Ball Screw Drive
$4,940.00
- 171" Max Lift Height, Ball Screw Drive
$6,330.00
- No Crating - Some assembly is required.
$0.00
- 36" x 54" Platform
$0.00
- 53" Unit Shipped Crated & Fully Assembled
$460.00
- 36" x 60" or 42" x 54" Platform - Requires Extra Large Crate
$0.00
- 53" Unit Shipped Crated & Fully Assembled
$691.00
- Tower On The Left
$0.00
- Tower On The Right
$0.00
- AC Powered
$0.00
- DC Battery Powered - Battery provides 15-20 cycles during power outage. Batteries included.
$1,001.00
- A commercial electronics control board allows operation with doors, gates, multiple call/send controls, and other devices.
$0.00
- Commercial Electronics Control Board
$0.00
- 36" x 54" Straight Thru (34" Usable Width)
$0.00
- 36" x 60" Straight Thru (34" Usable Width)
$246.00
- 42" x 54" Straight Thru (40" Usable Width)
$491.00
- 36" x 54" 90 Degree (34" Usable Width)
$368.00
- 36" x 60" 90 Degree (34" Usable Width)
$492.00
- 42" x 54" 90 Degree (40" Usable Width)
$737.00
- Straight Thru or 90 Degree
$0.00
- Same Side Entry & Exit - Lift height must be 101" or greater.
$368.00
- Lifts 8' and over that are not in a hoistway require a platform gate or an interlock for a customer provided gate.
$0.00
- No Platform Gate
$0.00
- Left Swing 36" Wide Straight Thru Platform Gate with Interlock
$615.00
- Right Swing 36" Wide Straight Thru Platform Gate with Interlock
$615.00
- Left Swing 42" Wide Straight Thru Platform Gate with Interlock
$861.00
- Right Swing 42" Wide Straight Thru Platform Gate with Interlock
$861.00
- Left Swing 90 Degree Platform Gate with Interlock
$984.00
- Right Swing 90 Degree Platform Gate with Interlock
$984.00
- Paddle Controls with Emergency Stop Button
$0.00
- Emergency Alarm & Lighted Button
$208.00
- Keylocks for Controls
$35.00
- 42" High Side Walls
$0.00
- Solid Platform with Safety Pan
$0.00
- Inside Grab Bar
$0.00
- Fixed Ramp
$0.00
- Automatic Ramp
$0.00
- No Ramp with Pit Switch Option
$123.00
- Call/Send Control Station (each)
$119.00
- Wireless Call/Send Control Stations (pair)
$479.00
- Keylocks for Controls (each)
$34.00
- Landing gates below include an interlock and a call/send control built into the gate.
$0.00
- Left Swing 36" Wide Landing Gate with Interlock & Call/Send Control (each)
$809.00
- Right Swing 36" Wide Landing Gate with Interlock & Call/Send Control (each)
$809.00
- Left Swing 42" Wide Landing Gate with Interlock & Call/Send Control (each)
$979.00
- Right Swing 42" Wide Landing Gate with Interlock & Call/Send Control (each)
$979.00
- Keylocks for Controls (each)
$34.00
- Landing gates below include an interlock only.
$0.00
- Left Swing 36" Wide Landing Gate with Interlock Only (each)
$739.00
- Right Swing 36" Wide Landing Gate with Interlock Only (each)
$739.00
- Left Swing 42" Wide Landing Gate with Interlock Only (each)
$909.00
- Right Swing 42" Wide Landing Gate with Interlock Only (each)
$909.00
- Keylocks for Controls (each)
$34.00
- No Door
$0.00
- Fire-Rated Hoistway Door with EMI - Left (each)
$2,079.00
- Fire-Rated Hoistway Door with EMI - Right (each)
$2,079.00
- Fire-Rated Hoistway Door with Electric Strike - Left (each)
$2,219.00
- Fire-Rated Hoistway Door with Electric Strike - Right (each)
$2,219.00
- Surface mount EMI interlocks below are for a customer provided door or gate.
$0.00
- Left Swing Top Landing Door/Gate EMI Interlock (each)
$409.00
- Right Swing Top Landing Door/Gate EMI Interlock (each)
$409.00
- Flush mount electric strike interlocks below are for a customer provided door or gate.
$0.00
- Top Landing Electric Strike Interlock - Metal Frame (each)
$409.00
- Bottom Landing Electric Strike Interlock - Metal Frame (each)
$409.00
- Top Landing Electric Strike Interlock - Wood Frame (each)
$409.00
- Bottom Landing Electric Strike Interlock - Wood Frame (each)
$409.00
- Other Interlock Options
$0.00
- Keyed Dead Latch for Flush Mount Electric Strike Interlock (each)
$139.00
- Wiring For Interlock (per landing)
$159.00
- Anchor Bolt Kit
$0.00
- Tower Braces
$155.00
- 3rd Stop Wiring Charge
$493.00
- Phone Jack
$138.00
- Emergency Light
$138.00
- Fascia Panel (per foot)
$59.00
- Automatic Door Opener - Requires Upgraded Electronics
$2,349.00
- Free Liftgate Service on 53" Units As Requested
$0.00
Customer Reviews
| 1 review | ||
|
|
|
1 |
|---|---|---|
|
|
|
0 |
|
|
|
0 |
|
|
|
0 |
|
|
|
0 |
Sort by
AmeriGlide Hercules II Commercial Vertical Wheelchair Lift |
|
|
Jan 30, 2011 10:50 PM
|
|
|---|---|
| Mike the General Contractor from Louisville, KY would recommend this to a friend. | |
| A Little About Myself |
Project Manager for general Contractor
|
| Pros |
AmeriGlide delivered their Hercules II Commercial Vertical Wheelchair Lift exactly how it was ordered, on time, and with no extra charges. Installation went smooth and instructions were clear. |
| Cons |
None to note
|
| Service & Delivery |
Because of the front end work by the Sales representative everything when very smooth. Delivery was on time and as discussed. Service has not been an issue but neither has the performance of the AmeriGlide Hercules II Commercial Vertical Wheelchair Lift.
|
|
I was great to work with a company that knows their product and truly meets the customer's expectations.
|
|
| 8 of 8 people found this review helpful | |
