AmeriGlide Hercules II Residential Reconditioned Lift
Call 1 (877) 852-3217 for the lowest price!
AmeriGlide's Hercules II Residential Reconditioned Lift comes to you in like-new condition and has a 30 day parts warranty. It includes all the features that make it the correct choice for most residential applications - right out of the box. Some assembly required.
Features include a solid platform, a safety pan switch, paddle-type platform controls, and top and bottom limit switches. This lift is both ASME A18.1, Section 5 and CSA B44.1 - ASME 17.5 compliant.
Features include a solid platform, a safety pan switch, paddle-type platform controls, and top and bottom limit switches. This lift is both ASME A18.1, Section 5 and CSA B44.1 - ASME 17.5 compliant.
Additional Images
Click on an image to enlarge.
- Lifting Capacity: 600 lb
- Standard Lift Height: 53"
- Maximum Lift Height Upgrade: 171"
- Lift Speed (FPM): 10
- Maximum Stops: 3
- Portable: No
- Arrives Assembled: No
- Drive System: Acme Screw Drive
- Optional Drive Systems: None Available
- Battery Powered Option: Yes
- Constant Pressure Platform Control: Yes
- Emergency Stop Platform Control: Included
- Alarm Button: Optional Audible Alarm
- Keyed Platform Control: Optional
- Call-Send Controls: Optional Non-Keyed & Keyed Call-Send
- Platform Type: Solid with Non-Skid Coating
- Platform Size: 36" x 48" Platform (34" Usable Width)
- Optional Platform Sizes: 36" x 54", 36" x 60", 42" x 54" (40" Usable Width)
- Platform Configuration: Straight-Thru Access
- Optional Platform Configurations: Same Side Entry-Exit, Adjacent Access
- Upper Landing Gate: Optional
- Upper Access Ramp: None Available
- Lower Access Ramp: Automatic Folding, Optional Fixed
- Grab Rail: Included
- Guard Panel: 36", Optional 42"
Product Video
- Lifting Height
- Crating & Assembly
- Tower Orientation
- Power Source
- Electronics
- Portable Package
- Platform Type
- Platform Access
- Platform Gate
- Platform Controls
- Platform Control Options
- Platform Options
- Ramp Type & Pit Switch
- Landing Controls
- Landing Gate
- Fire Rated Doors
- Interlocks
- Accessories
- Additional Delivery Services
- 53" Max Lift Height, Acme Screw Drive
$0.00
- 77" Max Lift Height, Acme Screw Drive
$660.00
- 101" Max Lift Height, Acme Screw Drive
$1,680.00
- 125" Max Lift Height, Acme Screw Drive
$3,150.00
- 149" Max Lift Height, Ball Screw Drive
$4,780.00
- 171" Max Lift Height, Ball Screw Drive
$6,040.00
- No Crating - Some assembly is required.
$0.00
- 36" x 48" or 36" x 54" Platform
$0.00
- 53" Unit Shipped Crated & Fully Assembled
$460.00
- 36" x 60" or 42" x 54" Platform - Requires Extra Large Crate
$0.00
- 53" Unit Shipped Crated & Fully Assembled
$691.00
- Tower On The Left
$0.00
- Tower On The Right
$0.00
- AC Powered
$0.00
- DC Battery Powered - Battery provides 15-20 cycles during power outage. Batteries included.
$1,001.00
- A standard electronics control board will work with a landing gate, one call/send only, and 36" side walls.
$0.00
- Standard Electronics Control Board
$0.00
- A commercial electronics control board allows operation with doors, gates, multiple call/send controls, and other devices.
$0.00
- 42" high side walls require a Commercial Electronics Control Board
$0.00
- Commercial Electronics Control Board
$309.00
- Ball Screw Drive Models Include A Commercial Electronics Control Board
$0.00
- None
$0.00
- Portable Package
53" or 77" Max Lift Height
36" x 54" Straight Thru Platform
Platform Gate On Exit Side Included$1,614.00
- Portable Package also includes an Automatic Ramp and Safety Pan
$0.00
- 36" x 48" Straight Thru (34" Usable Width)
$0.00
- 36" x 54" Straight Thru (34" Usable Width)
$154.00
- 36" x 60" Straight Thru (34" Usable Width)
$246.00
- 42" x 54" Straight Thru (40" Usable Width)
$491.00
- 36" x 54" 90 Degree (34" Usable Width)
$368.00
- 36" x 60" 90 Degree (34" Usable Width)
$492.00
- 42" x 54" 90 Degree (40" Usable Width)
$737.00
- Straight Thru or 90 Degree
$0.00
- Same Side Entry & Exit - Lift height must be 101" or greater.
$368.00
- Lifts 8' and over that are not in a hoistway require a platform gate or an interlock for a customer provided gate.
$0.00
- Platform gates require 42" high side walls (found below).
$0.00
- No Platform Gate
$0.00
- Left Swing 36" Wide Straight Thru Platform Gate with Interlock
$615.00
- Right Swing 36" Wide Straight Thru Platform Gate with Interlock
$615.00
- Left Swing 42" Wide Straight Thru Platform Gate with Interlock
$861.00
- Right Swing 42" Wide Straight Thru Platform Gate with Interlock
$861.00
- Left Swing 90 Degree Platform Gate with Interlock
$984.00
- Right Swing 90 Degree Platform Gate with Interlock
$984.00
- Paddle Controls with Emergency Stop Button
$0.00
- Emergency Alarm & Lighted Button
$208.00
- Keylocks for Controls
$35.00
- Solid Platform with Safety Pan
$0.00
- Inside Grab Bar
$0.00
- 42" high side walls are required for lifts 8' and taller.
$0.00
- 42" high side walls are required for ANY lift with a platform gate.
$0.00
- 36" High Side Walls
$0.00
- 42" High Side Walls
$154.00
- 42" high side walls require a Commercial Electronics Control Board
$0.00
- Automatic Ramp
$0.00
- Fixed Ramp
$0.00
- No Ramp with Pit Switch Option
$123.00
- Call/Send Control Station (each)
$119.00
- Wireless Call/Send Control Stations (pair)
$479.00
- Keylocks for Controls (each)
$34.00
- Landing gates below include an interlock and a call/send control built into the gate.
$0.00
- Left Swing 36" Wide Landing Gate with Interlock & Call/Send Control (each)
$809.00
- Right Swing 36" Wide Landing Gate with Interlock & Call/Send Control (each)
$809.00
- Left Swing 42" Wide Landing Gate with Interlock & Call/Send Control (each)
$979.00
- Right Swing 42" Wide Landing Gate with Interlock & Call/Send Control (each)
$979.00
- Keylocks for Controls (each)
$34.00
- Landing gates below include an interlock only.
$0.00
- Left Swing 36" Wide Landing Gate with Interlock Only (each)
$739.00
- Right Swing 36" Wide Landing Gate with Interlock Only (each)
$739.00
- Left Swing 42" Wide Landing Gate with Interlock Only (each)
$909.00
- Right Swing 42" Wide Landing Gate with Interlock Only (each)
$909.00
- Keylocks for Controls (each)
$34.00
- No Door
$0.00
- Fire-Rated Hoistway Door with EMI - Left (each)
$2,079.00
- Fire-Rated Hoistway Door with EMI - Right (each)
$2,079.00
- Fire-Rated Hoistway Door with Electric Strike - Left (each)
$2,219.00
- Fire-Rated Hoistway Door with Electric Strike - Right (each)
$2,219.00
- Surface mount EMI interlocks below are for a customer provided door or gate.
$0.00
- Left Swing Top Landing Door/Gate EMI Interlock (each)
$409.00
- Right Swing Top Landing Door/Gate EMI Interlock (each)
$409.00
- Flush mount electric strike interlocks below are for a customer provided door or gate.
$0.00
- Top Landing Electric Strike Interlock - Metal Frame (each)
$409.00
- Bottom Landing Electric Strike Interlock - Metal Frame (each)
$409.00
- Top Landing Electric Strike Interlock - Wood Frame (each)
$409.00
- Bottom Landing Electric Strike Interlock - Wood Frame (each)
$409.00
- Other Interlock Options
$0.00
- Keyed Dead Latch for Flush Mount Electric Strike Interlock (each)
$139.00
- Wiring For Interlock (per landing)
$159.00
- Anchor Bolt Kit
$0.00
- Tower Braces
$155.00
- 3rd Stop Wiring Charge
$493.00
- Phone Jack
$138.00
- Emergency Light
$138.00
- Fascia Panel (per foot)
$59.00
- Automatic Door Opener - Requires Upgraded Electronics
$2,349.00
- Free Liftgate Service on 53" Units As Requested
$0.00
Customer Reviews
This product currently has no reviews. Would you like to leave one?
